1.260,00DKK

OS OCA-3070HV ESC 70 Amp
[OCA-3070HV]

OCA-3100HV ESC motor styring

Recommended O.S.Brushless motors: OMA5020-490 / OMA5025-375

Input signal period	50~400Hz
Voltage Range	14.8V-52.2V(4S LiPo-12S LiHV)
Maximum peak current	90A (5 seconds, 20℃, cooling air 5m/s)
Maximum current	70A (180 seconds, 20℃, cooling air 5m/s)
Intemal BEC	None (Input signals are insulated by a photocoupler.)
Advance Timing	Fixed 0~25° adjustable by 1°
PWM Frequency	Selectable : 8kHz, 16kHz, 32kHz
Active Freewheel	ON/OFF
Braking force setting	OFF or adjustable 0~100% by 2%
Brake speed setting	Adjustable 0~2.0 sec. by 0.1 sec.
Current limit	OFF or adjustable 40~120% by 5%
Governor	ON/OFF
Governor	（(not for FAI F3A competitions）
Throttle mode	Automatic/Set value, Stop Position/Maximum Throttle Position
Outside dimension	37mm(W) x 95mm(L) x 16mm(H)
Weight	124g including lead wires and 4φ connectors
Batterie Leads	13AWG, 100mm length, covered by silicone tube
Motor Leads	14AWG, 100mm length, covered by silicone tube
Input signal leads	22AWG, 3-Wire (Black-red-white) 240±10mm
Setting leads	22AWG, 3-Wire (Brown-red-orange) 140±10mm
Setting	The parameters can be set with OCP-3 ESC programmer
Protective function	Start protection/Low voltage cutoff/Non signal cutoff/ Overheat protection/Anti-spark protection/ Automatic battery cell quantity recognizing system
